Product Description:
Discover the UY1200: the ultimate solution for all your battery
charging needs.
For the latest in charging technology, the UY1200 is equipped with
automatic multi-stage charging curves to effectively prolong the
life of your batteries. From lead-acid (flooded, gel, or AGM) to
lithium (LiFePO4, LiMn2O4, LiNiCoMnO2), this versatile charger can
do it all. Benefit from its advanced charging protection mechanisms
such as over-temperature, over-voltage, over-current, short
circuit, and reverse polarity safeguards for an unparalleled user
experience.
The UY1200: a break from traditional charging.
Stay informed with real-time LED indicators that display two-way
feedback. Its quality components like MCU control, Pulse Frequency
Modulation (PFM) technology, and current-fed half-bridge topology
guarantee outstanding efficiency, stability, and energy savings.
Additionally, it showcases a sleek aluminum alloy casing,handle
design, and temperature-controlled fan for easy portability.
Choose from two modes of use:
The default charging mode provides seamless charging, while
tech-savvy users can opt for either CAN or RS485 communication
interfaces for enhanced control. With a vivid voltage and current
display, the UY1200 empowers you with the latest in battery
charging technology.
Take your battery charging experience to the next level with the
UY1200.
With its cutting-edge features, robust design, and unparalleled
performance, the UY1200 is the ideal choice for powering your
batteries efficiently and effectively. Get yours today and embrace
the future of charging technology!
Features:
| Charger Model: | UY1200 |
| Housing: | Aluminium Alloy |
| Max Power: | 1200W |
| Dimensions: | 263x150x90mm |
| AC Input: | 100-120Vac/200-240Vac,47~63 Hz |
| Communication: | CAN, RS485,Bluetooth |
| Max Efficiency: | 89% |
| Operating Temperature: | -20 to 40℃ |
| Storage Temperature: | -40 to 70℃ |
| Noise: | <=40dB |
| Cooling: | Intelligent temperature control fan |
| Protection: | Over Current, Over Voltage, Over temperature, Short Circuit,
Reverse |
This device is everything you need to keep your power sources fully
charged:
- Multi-Battery Compatibility: It handles lead-acid and various
lithium batteries, so your charge will always be up-to-date.
- Automatic Multi-Stage Charging: It transitions through stages so
you can get the most from your charging experience.
- Charging Protection: You won't have to worry about over-voltage,
over-current, or other potential risk.
- LED Status Indicators: You'll get real-time updates on charging
progress so you're always in the loop.
- Efficient Topology: Using current-mode half-bridge circuitry,
you'll get maximum efficiency from your charging time.
- MCU Control and PFM Technology: This combination provides high
efficiency and stability.
- Voltage and Current Display: This makes it easier to track your
current charge.
- Durable Aluminum Alloy Casing: Enhance the durability and heat
dissipation of the device.
Technical Parameters:
| UY1200 |
| Specification | DC Voltage(Max) | (CC:A)
Charging current | Light Turning(A) |
| Li-ion | Lifepo4 | Lead acid | Lithium | Lead acid |
| 12V 50A | 12.6V/16.8V | 14.6V | 14.7V | 50A | 8%CC | 25%CC |
| 24V 35A | 25.2V/29.4V/33.6V | 29.2V | 29.4V | 35A |
| 36V 25A | 42V/46.2V | 43.8V | 44.1V | 25A |
| 48V 20A | 50.4V/54.6V/58.8V | 54.75V/58.4V | 58.8V | 20A |
| 60V 15A | 63V/67.2V/71.4V | 73V | 73.5V | 15A |
| 72V 12A | 79.8V/84V | 87.6V | 88.2V | 12A |
| 84V 11A | 88.2V | 102.2V | 107.8V | 11A |
| 96V 10A | 100.8V | 109.5V | 117.6V | 10A |
| 108V 8A | 113.4V | 120.45V | 132.3V | 8A |
| 120V 6A | 126V | 131.4V | 147V | 6A |
Applications:
Marine and Boating: The UY1200 is the perfect device for marine applications thanks to its
waterproof design. It can charge batteries for boats, yachts, and
marine equipment, providing a consistent power source for
navigation and onboard systems.
Recreational Vehicles: Campers, RVs, and trailers are all powered
by batteries. The UY1200, with its multi-bank charging capability, can charge multiple
batteries simultaneously, making outdoors activities more
convenient.
Industrial Equipment: The UY1200 is a power player in different industrial facilities, where it
helps ensure operational readiness of the equipment. Its
compatibility with various battery types and protection mechanisms
prevent workflow disruption.
Renewable Energy Systems: The UY1200 is a great choice for renewable energy systems that rely on
battery storage. It is ideal for charging batteries in solar energy
systems, wind energy systems, and more, so sustainable power
generation is possible.
